Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Horsepower: | 310hp |
|---|---|---|---|
| Emission Standard: | National IV | Brand Name: | Foton Ouman |
| Market Segement: | Logistics Transportation | Displacement: | 9.726L |
| Tire Number: | 6 | Driving Type: | 4X2 |
| High Light: | heavy duty tractor trailer,4x2 tractor unit,truck tractor 4x2 |
||
Foton Ouman ETX 5 Series Heavy Duty Truck 310HP 4X2 Tractor
Foton Ouman ETX 5 Series Heavy Truck is a high-performance tractor with a powerful power of 310 hp. It adopts 4X2 drive mode and is suitable for medium and long distance cargo transportation and hauling work. The model has excellent reliability and durability, and is adaptable to various complex road conditions and working environments. Foton Ouman ETX 5 Series Heavy Duty Truck adopts advanced technology and craftsmanship, combined with precise design, to provide users with excellent driving experience and stable performance. It is equipped with a comfortable cab and humanized interior configuration to provide a comfortable working environment. The tractor has high traction and carrying capacity and is capable of performing various cargo hauling tasks.
| Basic Information | |
| Driving form | 4X2 |
| Wheelbase: | 3400mm |
| Engine | Weichai WP10.310E40 |
| Transmission | Faster 9JS119 |
| Rear axle speed ratio | 4.38 |
| Length | 5.932m |
| Width | 2.495 m |
| Height | 3.41 m |
| Front wheelbase | 2020mm |
| Rear Wheelbase | 1865mm |
| Overall weight | 6.8 tons |
| Gross mass | 18 tons |
| Gross Tractor Mass | 36.005 tons |
| Maximum speed | 95km/h |
| Segment: | Standard |
| Origin | Shandong |
| Tonnage Class | Heavy Truck |
| Engine parameters | |
| Engine Model | Weichai WP10.310E40 |
| Engine Brand | Weichai |
| Number of cylinders | 6 |
| Fuel Type | Diesel |
| Cylinder arrangement | Inline |
| Displacement | 9.726L |
| Emission Standard | National IV |
| Maximum Horsepower | 310hp |
| Maximum Output Power | 228kW |
| Maximum torque | 1500N-m |
| Maximum torque speed | 1200-1500rpm |
| Rated Speed | 1900rpm |
| Technology: | Common Rail SCR |
| Cab parameters | |
| Number of passengers | 2 |
| Seat row | half row |
| Transmission parameters | |
| Transmission Model | Faster 9JS119 |
| Transmission Brand | Faster |
| Shift mode | Manual |
| Forward Gear | 9 |
| Reverse gears | 1 |
| Tank Material | Aluminum Alloy |
| Fuel tank capacity | 400L |
| Chassis Parameters | |
| Frame Size | 280mm |
| Rear Axle Description | Steyr Rear Axle 13T |
| Rear Axle Allowable Load | 13000kg |
| Speed ratio | 4.38 |
| Suspension | Steel Plate Spring |
| Number of Springs | Multi-Leaf |
| Clutch | Medium 430 |
| Steering | Domestic |
| Saddle | 50# |
| Tires | |
| Number of tires | 6 |
| Tire Size | 12.00R20 |
| Handling Configurations | |
| ABS Anti-Locking | -ABS |
| Interior Configuration | |
| Air conditioning | Manual |
| Note: The models that do not comply with the regulations of the People's Republic of China, such as National III/National IV/National V models, can no longer be licensed domestically, and are only for export, or domestic off-highway internal transit and other unlicensed areas. This parameter is for reference only, the actual model configuration in the store shall prevail. | |
PACKING AND SHIPPING
We find the best shipping solution according to the actual order size to reduce the transportation cost and save the transportation cost for customers Common shipping: bulk carrier, ro-ro ship,container ship, frame ship
(1) Waxing: carry out wax spraying treatment
(2) Packing: stabilized and fixed with steel wire to protect the trailer during transportation.
(3) Transportation: Reliable logistics services from well-known freight forwarding providers to make the transportation process safe and timely.
(4) In 80% of the cases, we can provide customers with 15-20 days delivery for regular trailers.
(5) We can ship all trucks and trailers and spare parts by all means of transportation.
(6) For 90% of our cargoes, we will ship by sea, by container or roll-on/roll-off/bulk/flatbed to all major continents, such as South America, the Middle East, Africa, Oceania, etc. We can also ship by road or by road to the neighboring countries of China, such as Russia, Tajikistan, Kazakhstan and Mongolia.
(7) For China's neighboring countries, such as Russia, Tajikistan, Kazakhstan, Mongolia, etc., we can ship by road or railroad transportation trucks.
(8) For light spare parts for urgent needs, we can ship them by international courier services, such as DHL, TNT, UPS or Fedex.
