Product Details:
Payment & Shipping Terms:
|
| Capacity: | 3 M3 | Drive Mode: | 4X2 |
|---|---|---|---|
| Wheel Base: | 3300mm | Color: | White, Silver, Yellow, Blue, Green |
| Brand: | Dongfeng | Steering: | LHD/RHD |
| Description | |
| Model: | EQ3095TL |
| Engine | |
| Model | Cummins B125-33 |
| Type | Diesel, Direct Injection,Turbo charged with Intercooler |
| Max. Engine Output (HP or KW/rpm) | 92 KW(125 HP) |
| Max. Tourque (N.m/rpm): | 410 Nm @ 1400-1600 rpm |
| Cylinder Displacement L/cc | 3900ml |
| Emission: | Euro 3 |
| Gear Box | MT / Forward 5 & Reverse 1 |
| Model | WLY5S550 |
| Suspension | Strengthen spring |
| Type | Spring leaf tablet: 9/11+8 |
| Brakes | Front&Rear drum,dual-circult service brakding system |
| Clutch | |
| Type: | Single,dry,diaphragm spring clutch⊙350 |
| Overall Dimensions (LxWxH) mm: | 5560×2100×2650 |
| axle (Front/Rear)kg: | 2800 / 8000 |
| Driving Type: | 4×2 |
| Wheel Base (mm): | 3300 |
| Min ground clearence (mm): | 248 |
| Vehicle Weight | |
| Curb weight (kg): | 3800 |
| Pay Load Capacity (kg): | 5600 |
| Gross vehicle weight (kg): | 9400 |
| Cabin: | 1+2 seats / 2 doors |
| Steering | |
| Type: | power steering gear |
| Wheels & Tyres | |
| Front: | Tire Number: 2, Tire Size: 8.25R16 |
| Rear: | Tire Number: 2, Tire Size: 8.25R16 |
| Mixing tanker specification | |
| Mixing capacity(m³) | 3 |
| tanker material | 16MnQ345 |
| Angel of inclination of mixing drum(°) | 16-18 |
| Feeding speed(m³/min) | 2 |
| Discharge speed(m³/min) | 2 |
| Residual ratio(%) | ＜0.7 |
| Mixing speed(r/min) | 0-18 |
| Transport mixing speed(r/min) | 3-4 |
| Water tanker(L) | 500 |
